Introducing the HIKMICRO Condor LRF
Key Features:
- Cutting-Edge Sensor: The Condor LRF features a <20mK NETD sensor, offering powerful imaging capabilities even in challenging weather conditions.
- Long-Range Accuracy: Equipped with a 1000m laser rangefinder, accurate to -1m, the Condor ensures precise distance measurement for stalking or observing.
- Rugged and Compact Design: Built with a rugged magnesium alloy housing and boasting an IP67 rating, the Condor is tough enough to withstand outdoor adventures while remaining lightweight and compact for easy portability.
- High-Resolution Display: With a 384 × 288 @ 12 um infrared detector and a 1024 × 768 OLED display, the Condor delivers superior image quality and detail recognition.
- Advanced Image Processing: Featuring Image Pro technology for enhanced detail recognition and Zoom Pro for digital zooming without loss of picture quality.
- Long Battery Life: The replaceable and rechargeable Li-ion battery offers up to 4.5 hours of continuous operation, ensuring extended usage during outdoor activities.
Ideal for Various Applications:
- Forest hunting
- Birdwatching
- Animal searching
- Adventuring
- Search and rescue operations
Experience powerful imaging capabilities and long-range accuracy with the HIKMICRO Condor LRF thermal monocular. Its advanced features and rugged design make it the perfect companion for outdoor enthusiasts and professionals alike.
Specification
|
Thermal Module |
|
|
Image Sensor |
VOx Uncooled Focal Plane Arrays |
|
Max. Resolution |
384 × 288 |
|
Frame Rate |
50 Hz |
|
Pixel Interval |
12 ?m |
|
Response Waveband |
8 ?m to 14 ?m |
|
NETD |
Less than 20 mK (@25°C), F# = 1.0 |
|
Lens (Focal Length) |
25 mm, f1.0 |
|
Focus Mode |
Focus Ring |
|
Detection Range |
1800 m |
|
Min. Focusing Distance |
3.5 m |
|
Magnification |
2.5× to 20× (8×) |
|
Image Display |
|
|
Display |
1024 × 768, 0.39 inch, OLED |
|
Palettes |
Black Hot, White Hot, Red Hot, Fusion |
|
FFC (Flat Field Correction) Mode |
Auto, Manual, External Correction |
|
Exit Pupil |
4 mm |
|
Eye Relief |
15 mm |
|
Diopter (Range) |
-5 D to 3 D |
|
Brightness Adjustment |
Yes |
|
Tone Adjustment |
Cold, Warm |
|
Contrast Adjustment |
Yes |
|
Image Pro |
Yes |
|
Zoom Pro |
Yes |
|
System |
|
|
Record Video |
Yes |
|
Capture Snapshot |
Yes |
|
Audio Recording |
Yes |
|
Standby Mode |
Yes |
|
Storage |
Yes |
|
PIP |
Yes |
|
Hotspot |
Yes |
|
Hot Track |
Yes |
|
Distance Measurement |
Yes |
|
Power Supply |
|
|
Battery Type |
Replaceable and Rechargeable Li-ion Battery |
|
Battery Operating Time |
4.5-hour continuous running with CVBS and hotspot function off (@25°C) |
|
Type-C Power Supply |
5 VDC, 2 A |
|
General |
|
|
Protection Level |
IP67 |
|
Dimension |
184.9 mm × 53 mm × 87.8 mm (7.28" × 2.09" × 3.46") |
|
Weight |
400 g without battery |
|
Working Temperature |
-30°C to 55°C |
|
Laser Rangefinder |
|
|
Safety Class for Laser |
Class 1 |
|
Wavelength |
905 nm |
|
Max. Measuring Range |
1000 m |
|
Measurement Accuracy |
± 1 m |
|
Min. Measuring Range |
10 m |
